LTC3611 e

lectricAl chArActeristics
The
l
denotes the specifications which apply over the full operating temperature range, otherwise specifications are at TA = 25°C. VIN = 15V unless otherwise noted. SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS Internal VCC Regulator
VINTVCC Internal VCC Voltage 6V < VIN < 30V, VEXTVCC = 4V l 4.7 5 5.6 V ΔVLDO(LOADREG) Internal VCC Load Regulation ICC = 0mA to 20mA, VEXTVCC = 4V –0.1 ±2 % VEXTVCC EXTVCC Switchover Voltage ICC = 20mA, VEXTVCC Rising l 4.5 4.7 V ΔVEXTVCC EXTVCC Switch Drop Voltage ICC = 20mA, VEXTVCC = 5V 150 300 m/V ΔVEXTVCC(HYS) EXTVCC Switchover Hysteresis 500 m/V
PGOOD Output
ΔVFBH PGOOD Upper Threshold VFB Rising 7 10 13 % ΔVFBL PGOOD Lower Threshold VFB Fal ing –7 –10 –13 % ΔVFB(HYS) PGOOD Hysteresis VFB Returning 1 2.5 % VPGL PGOOD Low Voltage IPGOOD = 5mA 0.15 0.4 V
Note 1:
Stresses beyond those listed under Absolute Maximum Ratings
Note 4:
The LTC3611 is tested under pulsed load conditions such that may cause permanent damage to the device. Exposure to any Absolute TJ ≈ TA. The LTC3611E is guaranteed to meet specifications from Maximum Rating condition for extended periods may affect device 0°C to 125°C junction temperature. Specifications over the –40°C to reliability and lifetime. 125°C operating junction temperature range are assured by design,
Note 2:
T characterization and correlation with statistical process controls. The J is calculated from the ambient temperature TA and power dissipation P LTC3611I is guaranteed over the full –40°C to 125°C operating junction D as follows: T temperature range. Note that the maximum ambient temperature J = TA + (PD • 28°C/W) (θJA is simulated per JESD51-7 high effective thermal conductivity test board) consistent with these specifications is determined by specific operating θ conditions in conjunction with board layout, the rated package thermal JC = 1°C/W (θJC is simulated when heatsink is applied at the bottom of the package) impedance and other environmental factors.
Note 3:
The LTC3611 is tested in a feedback loop that adjusts VFB to achieve a specified error amplifier output voltage (ITH). The specification at 85°C is not tested in production. This specification is assured by design, characterization, and correlation to testing at 125°C. typicAl perForMAnce chArActeristics
Transient Response Transient Response (Discontinuous Mode) Start-Up
VOUT VOUT 200mV/DIV 200mV/DIV RUN/SS 2V/DIV IL IL 5A/DIV 5A/DIV VOUT 1V/DIV ILOAD ILOAD IL 5A/DIV 5A/DIV 5A/DIV 3611 G01 3611 G02 3611 G03 40µs/DIV 40µs/DIV 40ms/DIV LOAD STEP 0A TO 8A LOAD = 1A TO 10A VIN = 25V VIN = 25V VIN = 25V VOUT = 2.5V VOUT = 2.5V VOUT = 2.5V RLOAD = 0.5Ω FCB = 0 FCB = INTVCC FIGURE 6 CIRCUIT FIGURE 6 CIRCUIT FIGURE 6 CIRCUIT 3611fd Document Outline Features Applications Description Typical Application Absolute Maximum Ratings Pin Configuration order information Electrical Characteristics Typical Performance Characteristics Pin Functions Functional Diagram Operation Applications Information Typical Applications Package Description Revision History Typical Application Related Parts
