AD707–SPECIFICATIONS (@ +25
8
C and
6
15 V, unless otherwise noted) AD707J/A AD707K/B Conditions Min Typ Max Min Typ Max Units
INPUT OFFSET VOLTAGE Initial 30
90
10
25
µV vs. Temperature 0.3 1.0 0.1
0.3
µV/°C TMIN to TMAX 50 100 15
45
µV Long-Term Stability 0.3 0.3 µV/month Adjustment Range R2 = 20 kΩ (Figure 19) ±4 ±4 mV INPUT BIAS CURRENT 1.0 2.5 0.5 2.0 nA TMIN to TMAX 2.0 4.0 1.5 4.0 nA Average Drift 15 40 15 40/40/40 pA/°C OFFSET CURRENT VCM = 0 V 0.5 2.0 0.3
1.5
nA TMIN to TMAX 2.0 4.0 1.0
2.0
nA Average Drift 2 40 1 25/25/35 pA/°C INPUT VOLTAGE NOISE 0.1 Hz to 10 Hz 0.23 0.6 0.23 0.6 µV p-p f = 10 Hz 10.3 28 10.3 18 nV/√Hz
OBSOLETE
f = 100 Hz 10.0 13.0 10.0 12 nV/√Hz f = 1 kHz 9.6 11.0 9.6 11.0 nV/√Hz INPUT CURRENT NOISE 0.1 Hz to 10 Hz 14 35 14 30 pA p-p f = 10 Hz 0.32 0.9 0.32 0.8 pA/√Hz f = 100 Hz 0.14 0.27 0.14 0.23 pA/√Hz f = 1 kHz 0.12 0.18 0.12 0.17 pA/√Hz COMMON-MODE REJECTION RATIO VCM = ± 13 V
120
140
130
140 dB TMIN to TMAX 120 140
120
140 dB OPEN-LOOP GAIN VO = ± 10 V RLOAD ≥ 2 kΩ
3
13
5
13 V/µV TMIN to TMAX
3
13 3 13 V/µV POWER SUPPLY REJECTION RATIO VS = ± 3 V to ± 18 V
110
130
115
130 dB TMIN to TMAX 110 130 110 130 dB FREQUENCY RESPONSE Closed-Loop Bandwidth 0.4 0.9 0.4 0.9 MHz Slew Rate 0.12 0.3 0.12 0.3 V/µs INPUT RESISTANCE Differential 24 100 45 200 MΩ Common Mode 200 300 GΩ OUTPUT CHARACTERISTICS Voltage RLOAD ≥ 10 kΩ
13.5
14
13.5
14 ±V RLOAD ≥ 2 kΩ
12.5
13.0
12.5
13.0 ±V RLOAD ≥ 1 kΩ
12.0
12.5
12.0
12.5 ±V RLOAD ≥ 2 kΩ TMIN to TMAX 12.0 13.0
12.0
13.0 ±V OPEN-LOOP OUTPUT RESISTANCE 60 60 Ω POWER SUPPLY Current, Quiescent 2.5
3
2.5
3
mA Power Consumption, No Load VS = ± 15 V 75
90
75
90
mW VS = ± 3 V 7.5
9.0
7.5
9.0
mW NOTES All min and max specifications are guaranteed. Specifications in
