Diodes Incorporated Introduces World's First Power Switch to Fully Support USB Type-C Power Delivery and Hot-Swap Operation

Diodes DPS1133

Diodes Incorporated introduced the DPS1133. This single-channel power switch is the world’s first high-voltage power switch designed to meet all the demanding protection and fast-role swap requirements of USB Type-C™ ports. As such, it addresses the full gamut of mobile and desktop computing devices and peripherals, and numerous other applications in the consumer electronics, mobile communications, industrial, and medical markets, such as smartphones, AR/VR goggles, robotics, automotive infotainment, and home electronics.

Diodes - DPS1133

Specifically, the DPS1133 protects the VBUS lines to and from USB Type-C connectors, meets the fast role swap (FRS) timing criteria defined by the latest Release 3.0 Power Delivery Specification, and supports all the allowed USB-C port operational modes: downstream facing (DFP), upstream facing (UFP), and dual-role (DRP). Designed to operate between 4.5 V and 24 V, the DPS1133 can either act to provision or consume power at up to 3.5 A through a USB Type-C connector, automatically protecting and recovering from fault conditions like over-voltage, over-current, short-circuit, reverse-voltage, and over-temperature, without the intervention of a system controller.

The DPS1133 Functional Block Diagram
The DPS1133 Functional Block Diagram.

The low on-state resistance of the DPS1133 power switch (typically ≤30 mΩ) enables the 3.5 A maximum continuous current and helps minimize power dissipation, while the thermally efficient QFN4040-17 package ensures a sufficiently low surface temperature during operation. Usability is enhanced through the ability to use external resistors to adjust many device parameters, such as voltage and current limits, and ramp times. Control pins also allow the input and output ports to be discharged through an internal resistor.
