AD5940/ AD5941 Data Sheet HIGH SPEED DAC CIRCUITS
The 12-bit high speed DAC generates an ac excitation signal 4. If the internal high speed oscillator is selected as the system when measuring the impedance of an external sensor. Control clock source, ensure that the 16 MHz option is selected. Set the DAC output signal directly by writing to a data register or HSOSCCON, Bit 2 = 1. by using the automated waveform generator block. The high
High Power Mode
speed DAC signal is fed to an excitation amplifier designed specifically to couple the ac signal on top of the normal dc High power mode increases the bandwidth supported by the bias voltage of a sensor. high speed DAC amplifiers. Use high power mode when the high speed DAC frequency is greater than 80 kHz. To enter high
HIGH SPEED DAC OUTPUT SIGNAL GENERATION
power mode, a number of register writes are required. There are two ways of setting the output voltage of the high To configure the high speed DAC for high power mode, take speed DAC, as follows: the following steps: • A direct write to the DAC code register, HSDACDAT. This 1. Set the PMBW register, Bit 0 = 1. Power consumption is register is a 12-bit register where the most significant bit increased, but the output signal bandwidth increases to a (MSB) is a sign bit. Writing 0x800 results in a 0 V output. maximum of 200 kHz. In high power mode, the system Writing 0x200 results in negative full-scale, and writing clock to the DAC and the ADC is 32 MHz. 0xE00 results in positive full-scale. 2. Ensure that CLKSEL Bits[1:0] select a 32 MHz clock source. • Use the automatic waveform generator. The waveform For example, to select an internal high speed oscillator, set generator can be programmed to generate fixed frequency, CLKSEL Bits[1:0] (SYSCLKSEL) = 00. Ensure that the system fixed amplitude signals including, sine, trapezoid, and clock divide ratio is 1 (CLKCON0 Bits[5:0] = 0 or 1). square wave signals. If the user selects the sine wave, options 3. If the internal high speed oscillator is selected as the system exist to adjust the offset and phase of the output signal. clock source, ensure that the 32 MHz option is selected.
POWER MODES OF THE HIGH SPEED DAC CORE
Clear HSOSCCON, Bit 2 = 0. The reference source of the high speed DAC is an internal 1.82 V
Hibernate Mode
precision reference voltage (VREF_1V82 pin). There are three basic When the AD5940/AD5941 enter hibernate mode, the clocks to modes of operation for the high speed DAC that trade off between the high speed DAC circuits are clock gated to save power. power consumption vs. output speed: low power mode, high power When in active mode and the high speed DAC is not in use, mode, and hibernate mode. The high speed DAC can also be disable the clocks to save power. placed into hibernate mode when inactive.
HIGH SPEED DAC FILTER OPTIONS Low Power Mode
The output stage of the high speed DAC features a configurable Low power mode is used when the high speed DAC output reconstruction filter. The configuration of the reconstruction signal frequency is <80 kHz. filter is dependent on the output signal frequency of the DAC. When configuring the high speed DAC for low power mode, Bits[3:2] in the PMBW register configure the 3 dB cutoff take the following steps: frequency of the reconstruction filter. Ensure that the cutoff 1. Clear the PMBW register (Bit 0 = 0). frequency is higher than the required DAC output frequency. 2. In this mode, the system clock to the high speed DAC and • PMBW Bits[3:2] = 01 for optimal performance if the DAC the ADC is 16 MHz. update frequency is ≤50 kHz. 3. Ensure that CLKSEL, Bits[1:0] = 0 to select a 16 MHz, • PMBW Bits[3:2] = 10 for optimal performance if the DAC internal, high frequency oscillator clock source. Ensure the update rate is ≤100 kHz. system clock divide ratio is 1 (CLKCON0, Bits[5:0] = 0 or 1. • PMBW Bits[3:2] = 11 for optimal performance if the DAC update rate is up to 250 kHz.
