VIA0250DD
www.vishay.com Vishay Semiconductors
PIN CONFIGURATION AND FUNCTIONS
V 1 8 V DD1 DD2 IN 2 7 OUT P P VIA0250DD top view IN 3 6 OUT N N GND 4 5 GND 1 2 Fig. 2 - VIA0250DD Package
PIN CONFIGURATION AND DESCRIPTION PIN NO. SYMBOL FUNCTION
1 VDD1 Power supply for isolator side 1 (3.0 V to 5.5 V) 2 INP Positive analog input (± 250 mV recommended for VIA0250DD) 3 INN Negative analog input 4 GND1 Ground 1, the ground reference for isolator side 1 5 GND2 Ground 2, the ground reference for isolator side 2 6 OUTN Negative output 7 OUTP Positive output 8 VDD2 Power supply for isolator side 2 (3.0 V to 5.5 V) Rev. 1.2, 02-Apr-2025
